Vyxalon™ Apex Drone Drive

The Vyxalon™ Apex Drone Drive is a next-generation electronic speed controller (ESC) designed for professional drone propulsion systems. Engineered for industrial UAV, UAS, and mission-critical drone applications, the Vyxalon Apex Drone Drive combines advanced Gallium Nitride (GaN) power technology with high-speed Field-Oriented Control (FOC) to deliver exceptional propulsion efficiency, rapid throttle response, and superior thermal performance.

Powered by Allient Intelligent Controls (AiC), the drive operates with up to 100 kHz PWM switching, 25 kHz control loops, and support for both sensorless and encoder-based FOC. The Vyxalon Apex Drone Drive maximizes flight time, improves reliability, and provides precise motor control in the most demanding environments. Its lightweight IP67-rated aluminum enclosure, broad 4S – 14S voltage compatibility, and advanced protection features make it an ideal solution for professional and commercial drone platforms.

Benefits & Advantages

• Advanced GaN power technology reduces energy losses by up to 56% for longer flight times compared to conventional silicon MOSFET designs.
• High-speed 100 kHz PWM switching improves efficiency while minimizing heat generation.
• Industry leading 25 kHz current and velocity control loops deliver precise motor response and superior flight control.
• Rapid 0.5-second acceleration from zero to full speed.
• Low-noise, low-vibration operation enhances flight stability and payload performance.
• Active braking and propeller position holding improve maneuverability and safety.
• Stall recovery maintains field orientation for uninterrupted operation.
• Compact GaN electronics reduce controller size by up to 50% for easier integration.
• Lightweight 97 g aluminum housing with IP67 dust and water protection.
• Supports DroneCAN, DShot, PWM Digital Command, and optional Ethernet connectivity.

Market Segments & Applications

Defense: Defense and government UAV platforms, public safety and emergency response drones, heavy-payload and long-endurance drone systems

Industrial: Industrial inspection drones, commercial delivery UAVs, infrastructure inspection and utility monitoring

Robotics: Autonomous aerial robotics

Agriculture: Environmental monitoring and conservation missions, mapping, surveying, and geospatial drones, agriculture and precision farming UAVs
