Pyxmos™ Module Servo Drive
Pyxmos is a compact, versatile servo drive module engineered for seamless integration into embedded motion control systems. With advanced 20kHz high-speed control loops it delivers unmatched precision for mechatronic, robotic, and nanometer motion applications.
- EtherCAT and CANopen control networks
- 12-90VDC voltage input
- Max 15 Amps continuous
- 20kHz PWM motor control
- 20kHz torque, speed, and position control loops
- Incremental and absolute encoder inputs with advanced signal processing
High Density Connector Provides Compact Integration Solutions:
- PCB boards
- Industrial control panel mounting
- Multi-axis systems with backplane
- Motor and actuator integration
Pyxmos Design Services for OEMs:
- Design services provide a performance advantage through optimized hardware, fast control loops, and precise, application-tuned motion control
- Integration services provide measurable value by reducing engineering effort, simplifying integration, and enabling scalable production
Specifications Overview
-
Dimensions H x W x D (mm)80 x 33 x 83
-
Operating Temperature (ºC)0 - 55
-
Bus Voltage (VDC)12 - 90
-
Rated Current (ADC)5 - 15
-
Rated Power (W)50 - 1,350
-
Communication TypeCANopen, EtherCAT
-
Feedback TypeA/B, BiSS-C, EnDat 2.2, Halls, Sin/Cosine
-
IO4 analog inputs, 4 inputs, 4 outputs
